Aluminium Plates for Transportation

Lightweight aluminum alloys apply in transportation industry including high-speed railway transporation, subway, suburban railway vehicles and tankers, coal truck body structure parts, carriage panels, etc. With excellent mechanical properties, aluminum alloys have great potential in the manufacture of high-speed, lightweight, green, energy-saving and high comfortable rail transit vehicles.
aluminium plates for transportation| MUSEN Aluminum plates in transoprtation have advantages of high strength-toughness, high precision,excellent flatness, ultra-wide with max width up to  2650mm.
Alloy 5052,5083,5182,5454,,6061,6013,7075…
Temper O,H111,H112,H321,T6,T351…
Minimum Order Quantity 8000~15000 Kilograms
Surface Finish Mill Finished
Thickness 1.0 mm - 10.0 mm
Size/Dimension 4'X8',5'X10' ,1500*4000,1800*5000,2000*6000,Or as per orders.
Usage/Application Automative parts,High-Speed Rail,Rail train,Coal Vehicles, Bus, Truck Tankers,Truck Van refrigeretors…
Grade-Plates Alloy Temper Thickness Range(mm) Width(mm) Length(mm) Standards
Aluminum plates for coal vehicle 5083 O/H111/H321 5.0~10.0 mm 1200~2600 1000~12000  GB/T3880,YS/T622
Aluminum plates for tank truck 5454/5083/5182 O/H111/H321 5.0~10.0 mm 1800~2600 2000~12000
HIGH STRENGTH-TOUGHNESS Tensile Strength (Mpa) Yield Strength (Mpa) Breaking Elongation(A50%) Standards
TYPE PLATES 5182 H19 350~370 395~415 8~10 EN485
6061 T6 270~290 320~340 13~15 EN485
6013 T6 320~340 360~380 8~10 ASTM B209
7021 T6 450~470 490~510 13~15 EN485
7075 T6 480~500 570~590 13~15 ASTM B221M
